Pique Advanced SL 3
Cross-country is evolving beyond fast-and-flowy to fast-and-everything—technical terrain, all-day epics, and stage races. The new Pique Advanced SL 3 is …ready for it. Re-engineered for greater efficiency and control, this XC queen was built to slay switchbacks, rock gardens, and yesterday’s PRs.
highlights
1
2
3
4
5
6
7
8
9
10
11
12
13
size guide and geometry
This size guide is based on your body height. Sizing to be used as a reference only. Please check with a local authorized Liv dealer to determine the correct size.
KEY PERFORMANCE FACTORS
BUILT FOR SPEED
The new Advanced SL-grade composite frame is the lightest we’ve ever designed, achieving exceptional stiffness-to-weight so every pedal stroke returns power almost effortlessly, for swift and decisive acceleration and climbing. Tuned specifically for XC racing, the reengineered FlexPoint Pro Suspension is lighter, more compact, and more responsive.
BUILT FOR PERFORMANCE
The Pique Advanced SL is designed as a single optimized system. The new one- piece handlebar-stem with fully integrated cable routing keeps things light, clean, and responsive. Giant WheelSystems with Wide Guard rims give you robust sidewalls so you can run lower tire pressure for extra grip and puncture protection.
BUILT FOR RESULTS
The updated FlexPoint Pro suspension system offers 120mm of smooth, active rear-wheel travel, paired with a 120mm fork, giving you the control and stability you need when things get technical. The two-position flip chip lets you adjust your geometry for the perfect handling for the course. And the suspension lock-out provides hardtail-like efficiency when you’re climbing a hill or a podium.
SPECIFICATIONS
sizes
XS, S, M, L
colours
Deep Cove/Sea Sparkle
frame
Advanced SL-grade composite front and rear triangles, 120mm FlexPoint Pro suspension, flip chip, 12x148mm thru-axle
fork
Fox 34 SL Performance, 120mm, GRIP damper, Boost 15x110, 44mm offset, 3P remote lockout
shock
Fox Float SL Performance Elite, 3-position damper, 210/50, 3-position lockout
handlebar
Giant Integrated XC, alloy, 780mm, 9-degree upsweep
grips
Liv XC Pro, silicone
stem
Giant Integrated XC, alloy
seatpost
Giant Core dropper, remote XS&S: 100mm travel / 30.9 x 395mm M: 120mm travel / 30.9 x 395mm L: 120mm travel / 30.9 x 395mm
saddle
Liv Grit Core
pedals
platform [GC,GT]
shifters
Shimano Deore mechanical, 1x12
front derailleur
N/A
rear derailleur
Shimano Deore
brakes
Shimano BR-MT500, hydraulic, Giant TR55 rotors [F]180mm, [R]160mm
brake levers
Shimano BL-MT501
cassette
Shimano M6100, 10x51
chain
KMC X-12
crankset
Praxis Cadet HD M24, 32t, 55mm chainline XS: 165mm, S:170mm, M:170mm, L:170mm
bottom bracket
Praxis, press fit
rims
Giant XCA Alloy WheelSystem
hubs
[F] Giant MTB alloy, 6-bolt, [R] Giant alloy, alloy, 120T helical-bevel ratchet driver, 6-bolt
spokes
Sapim Laser
tyres
Maxxis Aspen 29x2.4, foldable, 120tpi, MaxxSpeed, EXO, tubeless
extras
tubeless prepared, 2.4inch max tire size, 34t max chainring size, MRP 1xCS chain guide, top cap computer mount
weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
*All specifications and prices listed are subject to change without notice.
